Rebar to Cold Rolled

Scott,

Thank you for that input.  I realize that.  But, Austin had asked three rather vague questions that I was responding to as simply as I could and keeping my answer as accurate as I could without getting too lengthy and detailed.

He did not ask about a specific type of joint or other factors.  I felt the briefest yet accurate answer was the best.  To the best of my knowledge, he could not go wrong using the fillers I suggested.  Depending upon factors from Table 2.1, which it is unknown if he even understands (no offense intended Austin), it could have been possible to mislead him.

He mainly wanted to know which processes were usable on the different grades of re-bar.  I told him with the disclaimer that there were times when the fillers would differ, though that may not have been perfectly clear.  I also directed him to the importance of having his own copy of D1.4 for reference.  With that in hand, he should be able to fill in any gaps I may have left.

There is no offense taken nor any directed to your response by me.  Just trying to clarify why I answered as I did.  Thank you for your input.

Have a Great Day,  Brent

Please visit our website for more information on this topic.

Metals USA carries carbon steel rebar in grades 40 and 60 both bare and also epoxy coated, along with A706 weldable rebar for any of your construction needs.

Structural steel rebar is an integral part of concrete construction. The term 'rebar' refers to the reinforcing bars used within concrete columns, beams, and decks. Because concrete is very strong in resisting compressive forces but weak in tensile strength, steel rebars are integrated into the concrete to improve tensile strength.

Rebar Markings

Markings on the rebar will indicate a standard set of information; production location, size, type and grade.

• Production mill: Location where the rebar was produced
• Size: Number sizes indicate rebar thickness (see chart below)

Rebar

Ft.

20'

40'

#3 (3/8")

0.38

7.5

15

#4 (1/2")

0.67

13.4

27

#5 (5/8")

1.04

20.9

42

#6 (3/4")

1.50

30.0

60

#7 (7/8")

2.04

40.9

82

With competitive price and timely delivery, Xingtai Steel sincerely hope to be your supplier and partner.

#8 (1")

2.670

53.4

106.8

#9 (1 1/8")

3.400

68

136

#10 (1 1/4")

4.30

86.0

172

Carbon Steel Rebar

Commonly known as black bar, or bare steel rebar, carbon steel rebar is used on almost all major construction projects. While the biggest weakness of black rebar is its tendency to corrode over time, bare steel rebar is usually the best available choice with respect to its value/tensile strength ratio.

Epoxy-Coated Rebar

Epoxy-coated rebar is black rebar with an epoxy coat. It has the same tensile strength as black rebar, but is up to 1,700 times more corrosion-resistant. It's important to note that the epoxy coating is very delicate, and precautions should be made in storage and installation. Applied anywhere concrete is subjected to corrosive conditions, such as exposure to de-icing salts or marine environments, epoxy-coated rebar is employed in bridges, parking structures, pavement, marine structures, and more.

A706 Weldable Rebar

Material with a carbon-equivalent of less than 0.55 can be welded, and the only rebar that is ready to weld is W grade (low alloy A706). A706 rebar is produced to meet this specification, and allows workers in the field to weld reinforcing systems together. Commonly used for bent caps, footings, joints, and oversized shafts, A706 is an industry standard for many types of concrete construction applications.

Grades: Rebar is graded according to its tensile strength, and the numbers associated with the different grades are used to indicate pounds per square inch. Grade 33 is the lowest strength and has a minimum yield strength of 33,000 PSI, grade 40 has a minimum yield strength of 40,000 PSI and a minimum tensile strength of 60,000 PSI, and grade 60 rebar has a minimum yield strength of 60,000 PSI and a minimum tensile strength of 90,000 PSI.

Metals USA offers a wide selection of Grade 40 Rebar and Grade 60 Rebar.

Rebar Lengths: Metals USA stocks standard lengths of rebar which are available in 20 foot and 40 foot lengths.
