One equipment of CYLION laser uncoiling/decoiler production line can realize four functions: decoiler, feeding, cutting and blanking. Break the traditional processing method. Automatic assembly line, coil in wire cutting, saving labor and improving production efficiency. Coil laser wire cutting is used for cutting carbon steel, stainless steel and various thin metal coils below 3mm (according to customer requirements). The lathe bed of this product adopts integral welding structure, which has high accuracy of form and position tolerance; Transmission: equipped with Techmech high-rigidity reducer, YYC grinding rack and pinion, Rexroth high-precision linear guide rail and other transmission mechanisms, with good rigidity and high precision, ensuring long-term high-precision operation; The FSCUT bus controller is used in the control system, which is a reasonable combination of laser cutting, machinery, numerical control technology and other technologies.
From feeding, uncoiling, leveling, cutting and blanking, the automatic design of the whole process saves labor, can realize the design of coil with zero waste, and improve the utilization efficiency of plates.
The machine levels the coil and manually adjusts the height of the press roller. The servo motor can adjust the rotating speed of the press roller. The press roller is made of hollow bearing steel. After medium frequency treatment, the surface hardness can reach 60. After hard chromium treatment and fine grinding, it has high hardness, good wear resistance, high leveling ability and precision, and the leveling precision is 0.01.
The uncoiler adopts cantilever structure after stress annealing treatment. High load-bearing frame, hydraulic expansion, ensure stable operation. Frequency conversion speed regulation, stable feeding, flexible operation, equipped with feeding trolley. The width of the coil ranges from 500mm to mm, and the maximum bearing capacity is kg.
Servo precision feeding device, followed by roller support, reduce sheet metal skid and curling, improve processing quality and material quality. The belt conveyor automatically sends the processed sheet metal parts to the unloading platform to realize automatic production, which helps manufacturers improve work efficiency and save labor costs.
Used for laser cutting of coil plate, the plate is flattened by decoiler machine first, which can realize on-line uninterrupted plate cutting, greatly save the feeding time of plate and cut continuously. Coil leveling fiber laser cutting machine, using sheet metal welding structure, bilateral gear and rack synchronous drive, automatic leveling coil, accurate feeding, stable and reliable movement, is an ideal choice for laser cutting of metal plate! It is a combination of laser cutting, mechanical manufacturing, numerical control technology and other technical sciences. One equipment can realize four functions: decoiler, feeding, cutting and blanking, breaking the traditional processing mode. Automatic assembly line, coil in wire cutting, saving labor and high efficiency. The optical path is unconstrained, the optical fiber transmission loss is small, and large-scale processing can be realized. Lower maintenance cost: no laser working gas; Optical fiber transmission without reflecting lenses; It can save a lot of maintenance costs. The software can realize the timely processing of various graphics and characters, and is simple and convenient to use. Energy saving and environmental protection, perfect smoke and dust removal system. Arrange pre-production capacity and production plan. It is widely used in stainless steel, carbon steel, manganese steel, galvanized sheet, various alloy plates, rare metals and other thin metal coils.
Today Leapion Laser introduces the unwinding leveling laser cutting machine with intelligent transmission and automatic unloading.
The traditional sheet metal processing method is to use the uncoiler to uncoil and level, and then send it to the shearing machine to cut it into a certain length of sheet, and finally manually transport the material to the laser cutting machine for cutting and unloading.
Most of the existing laser cutting machines can cut various shapes, but when the existing equipment is cutting, the sheet material is static, and the feeding and discharging cannot be carried out at the same time, which affects the processing speed of the strip.
Unwinding and leveling laser cutting machine production line can realize the four functions of opening and leveling, feeding, cutting and unloading with one device, breaking the traditional processing method. That is, the laser cutting machine is used for flying cutting (following cutting) during the strip movement. The purpose is to solve the problem of rapid cutting without molds for continuous metal and non-metal strips, so as to reduce the investment of cutting equipment and molds. Consume cost and effectively improve the utilization rate of materials.
Coil laser cutting equipment is mainly composed of CAD/CAM programming system, automatic unwinding, leveling system, servo automatic feeding, laser cutting system, automatic assembly line, online cutting of coil material, saving labor and improving efficiency.
1. The CNC laser cutting machine adopts a professional system to control the motor synchronization. The working table of the cutting machine is a crawler type cutting table, and the crawler type is equipped with a needle plate type cutting strip; during processing, the cutting table and the unwinding servo feeding are synchronized and run at the same speed. Realize coil sheet cutting.
The uncoiling and leveling laser cutting production line is suitable for the processing of metal coils within 3mm, the repeatability of positioning can reach ±0.03mm, and the positioning accuracy is within ±0.05mm/m.
2. The fuselage of the CNC laser cutting machine adopts a steel plate welding structure, and is tempered at high temperature to completely eliminate the welding stress.
During machining, CNC gantry milling machine is used to process the guide rails and rack installation surfaces on both sides of the bed at one time, ensuring the consistency of the accuracy of the guide rails and rack installation surfaces on both sides of the frame.
3. The correction wheel of the leveling machine is made of bearing steel, and the surface is thickened and electroplated, which is durable and wear-resistant. The operation is simple and convenient, all correction wheels are geared, and have their own backup pressure rollers, which can effectively enhance the rigidity of the correction wheels and improve the quality of correction.
4. Convenient feeding: The coil slitting machine integrates automatic uncoiling, leveling, feeding and slitting, which ensures the continuity of processing and production and improves processing efficiency.
5. Intelligent transfer, automatic unloading. Using belt conveyor and adjustable limiter device, the processed plate is automatically sent to the unloading platform.
6. Independent control cabinet
On the one hand, it can be dust-proof, all electrical components and laser sources are built in an independent control cabinet, and the dust-proof design is adopted to prolong the service life of electrical components.
On the other hand, the control cabinet is equipped with an air conditioner and an automatic constant temperature. This can prevent damage to components caused by overheating in summer.
The above-mentioned unwinding and leveling laser cutting production line and its characteristics are this LF-CO coil fiber laser cutting machine. If you want to know more about this LF-CO coil fiber laser cutting machine, please contact Leapion Laser directly .
One equipment of CYLION laser uncoiling/decoiler production line can realize four functions: decoiler, feeding, cutting and blanking. Break the traditional processing method. Automatic assembly line, coil in wire cutting, saving labor and improving production efficiency. Coil laser wire cutting is used for cutting carbon steel, stainless steel and various thin metal coils below 3mm (according to customer requirements). The lathe bed of this product adopts integral welding structure, which has high accuracy of form and position tolerance; Transmission: equipped with Techmech high-rigidity reducer, YYC grinding rack and pinion, Rexroth high-precision linear guide rail and other transmission mechanisms, with good rigidity and high precision, ensuring long-term high-precision operation; The FSCUT bus controller is used in the control system, which is a reasonable combination of laser cutting, machinery, numerical control technology and other technologies.
From feeding, uncoiling, leveling, cutting and blanking, the automatic design of the whole process saves labor, can realize the design of coil with zero waste, and improve the utilization efficiency of plates.
The machine levels the coil and manually adjusts the height of the press roller. The servo motor can adjust the rotating speed of the press roller. The press roller is made of hollow bearing steel. After medium frequency treatment, the surface hardness can reach 60. After hard chromium treatment and fine grinding, it has high hardness, good wear resistance, high leveling ability and precision, and the leveling precision is 0.01.
The uncoiler adopts cantilever structure after stress annealing treatment. High load-bearing frame, hydraulic expansion, ensure stable operation. Frequency conversion speed regulation, stable feeding, flexible operation, equipped with feeding trolley. The width of the coil ranges from 500mm to mm, and the maximum bearing capacity is kg.
Servo precision feeding device, followed by roller support, reduce sheet metal skid and curling, improve processing quality and material quality. The belt conveyor automatically sends the processed sheet metal parts to the unloading platform to realize automatic production, which helps manufacturers improve work efficiency and save labor costs.
Used for laser cutting of coil plate, the plate is flattened by decoiler machine first, which can realize on-line uninterrupted plate cutting, greatly save the feeding time of plate and cut continuously. Coil leveling fiber laser cutting machine, using sheet metal welding structure, bilateral gear and rack synchronous drive, automatic leveling coil, accurate feeding, stable and reliable movement, is an ideal choice for laser cutting of metal plate! It is a combination of laser cutting, mechanical manufacturing, numerical control technology and other technical sciences. One equipment can realize four functions: decoiler, feeding, cutting and blanking, breaking the traditional processing mode. Automatic assembly line, coil in wire cutting, saving labor and high efficiency. The optical path is unconstrained, the optical fiber transmission loss is small, and large-scale processing can be realized. Lower maintenance cost: no laser working gas; Optical fiber transmission without reflecting lenses; It can save a lot of maintenance costs. The software can realize the timely processing of various graphics and characters, and is simple and convenient to use. Energy saving and environmental protection, perfect smoke and dust removal system. Arrange pre-production capacity and production plan. It is widely used in stainless steel, carbon steel, manganese steel, galvanized sheet, various alloy plates, rare metals and other thin metal coils.
Today Leapion Laser introduces the unwinding leveling laser cutting machine with intelligent transmission and automatic unloading.
The traditional sheet metal processing method is to use the uncoiler to uncoil and level, and then send it to the shearing machine to cut it into a certain length of sheet, and finally manually transport the material to the laser cutting machine for cutting and unloading.
Contact us to discuss your requirements of Brass Laser Cutting Machine. Our experienced sales team can help you identify the options that best suit your needs.
Most of the existing laser cutting machines can cut various shapes, but when the existing equipment is cutting, the sheet material is static, and the feeding and discharging cannot be carried out at the same time, which affects the processing speed of the strip.
Unwinding and leveling laser cutting machine production line can realize the four functions of opening and leveling, feeding, cutting and unloading with one device, breaking the traditional processing method. That is, the laser cutting machine is used for flying cutting (following cutting) during the strip movement. The purpose is to solve the problem of rapid cutting without molds for continuous metal and non-metal strips, so as to reduce the investment of cutting equipment and molds. Consume cost and effectively improve the utilization rate of materials.
Coil laser cutting equipment is mainly composed of CAD/CAM programming system, automatic unwinding, leveling system, servo automatic feeding, laser cutting system, automatic assembly line, online cutting of coil material, saving labor and improving efficiency.
1. The CNC laser cutting machine adopts a professional system to control the motor synchronization. The working table of the cutting machine is a crawler type cutting table, and the crawler type is equipped with a needle plate type cutting strip; during processing, the cutting table and the unwinding servo feeding are synchronized and run at the same speed. Realize coil sheet cutting.
The uncoiling and leveling laser cutting production line is suitable for the processing of metal coils within 3mm, the repeatability of positioning can reach ±0.03mm, and the positioning accuracy is within ±0.05mm/m.
2. The fuselage of the CNC laser cutting machine adopts a steel plate welding structure, and is tempered at high temperature to completely eliminate the welding stress.
During machining, CNC gantry milling machine is used to process the guide rails and rack installation surfaces on both sides of the bed at one time, ensuring the consistency of the accuracy of the guide rails and rack installation surfaces on both sides of the frame.
3. The correction wheel of the leveling machine is made of bearing steel, and the surface is thickened and electroplated, which is durable and wear-resistant. The operation is simple and convenient, all correction wheels are geared, and have their own backup pressure rollers, which can effectively enhance the rigidity of the correction wheels and improve the quality of correction.
4. Convenient feeding: The coil slitting machine integrates automatic uncoiling, leveling, feeding and slitting, which ensures the continuity of processing and production and improves processing efficiency.
5. Intelligent transfer, automatic unloading. Using belt conveyor and adjustable limiter device, the processed plate is automatically sent to the unloading platform.
6. Independent control cabinet
On the one hand, it can be dust-proof, all electrical components and laser sources are built in an independent control cabinet, and the dust-proof design is adopted to prolong the service life of electrical components.
On the other hand, the control cabinet is equipped with an air conditioner and an automatic constant temperature. This can prevent damage to components caused by overheating in summer.
The above-mentioned unwinding and leveling laser cutting production line and its characteristics are this LF-CO coil fiber laser cutting machine. If you want to know more about this LF-CO coil fiber laser cutting machine, please contact Leapion Laser directly .
Are you interested in learning more about Double Exchange Platforms Sheet and Tube Laser Cutting Machine? Contact us today to secure an expert consultation!
